HETAI Heavy Duty 870 Engraving Machine

HETAI Heavy Duty 870 Engraving Machine
Travel (X/Y/Z):800 mm / 700 mm / 300 mm
Worktable Size:800 mm × 700 mm
Spindle Type:BT30
Spindle Speed:Up to 18,000 RPM
Spindle Motor Power:5.5 kW or optional 7.5 kW
Control System:Mitsubishi E80 CNC system
Tool Magazine:12-tool Automatic Tool Changer (ATC)
Rapid Traverse Speed (X/Y/Z):15,000 mm/min
Cutting Feed Rate: 1–10,000 mm/min
Positioning Accuracy: ±0.005 mm
Repeatability:±0.003 mm
Max Load on Table:600 kg
Machine Weight:Approximately 4,500 kg
Machine Dimensions (L×W×H):2600 mm × 2300 mm × 2600 mm
Year of Manufacture:2022
